YAOAN PEEK Thick Plate Sheet Board Extrusion Line, PEEK Rods Making Machine
I. Brand & Enterprise Strength
YAOAN is a professional top brand in China, focusing on the R&D, production and sales of high-performance special engineering plastic profiles. We own independent core R&D technologies and large-scale production bases. Covering a factory area of 80,000 square meters, the company is equipped with standardized production workshops, precision processing equipment and a complete quality inspection system, realizing a full closed-loop operation of independent R&D, independent production and independent quality inspection for high-end PEEK and POM plastic profiles. With years of in-depth experience in the field of high-performance plastic extrusion molding, we rely on mature craftsmanship and self-developed production equipment to supply high-stability and high-quality PEEK thick plates sheets boards bars for industrial manufacturing, precision equipment, aerospace, medical chemical and other fields, with strong capabilities in customized production and bulk supply.
II. Product Overview
PEEK (Polyether Ether Ketone) thick plates sheets boards is a semi-crystalline thermoplastic special engineering plastic profile with top comprehensive performance in the industry. YAOAN PEEK thick plates sheets boards are refined from high-purity PEEK and POM virgin resins through precision extrusion molding technology. The product integrates ultra-high mechanical strength, high temperature resistance, wear resistance, corrosion resistance, self-lubrication, insulation and flame retardancy. It can replace part of metal materials and is widely used for processing various precision, high-load and extreme-working-condition parts, serving as a core raw material for high-end industrial lightweight and precision transformation.
III. Core Production Configuration & Process Advantages
We adopt a full set of self-adapted precision thick plates sheets boards extrusion production lines specially customized for high-end PEEK and POM bar production. Featuring high equipment precision and strong process stability, the production line ensures uniform density, accurate dimensions and stable performance of finished products. The core production equipment configuration is as follows:
|
No.
|
Equipment Name
|
Quantity
|
Function
|
|
1
|
AFφ55-25 Single Screw Extruder
|
1 Set
|
Realizes uniform high-temperature melting and plasticization of PEEK and POM resins, stably extrudes billets, and ensures consistent raw material molding quality.
|
|
2
|
AF-1300 Caterpillar Haul-off Machine
|
1 Set
|
Precisely controls the extrusion speed and tension of bars, avoids finished product bending and uneven thickness, and guarantees high straightness accuracy.
|
|
3
|
AF-1300 Quenching Device
|
1 Set
|
Quickly shapes extruded billets, optimizes the internal crystal structure of materials, and improves product hardness and structural stability.
|
|
4
|
AF-2.2M Cooling Stand
|
1 Set
|
Completes primary gradient cooling, releases internal stress through slow temperature reduction, and prevents subsequent deformation and cracking of bars.
|
|
5
|
AF-650 Saw Cutter
|
1 Set
|
Implements high-precision fixed-length cutting with smooth and burr-free notches and controllable dimensional errors, suitable for subsequent precision processing.
|
|
6
|
AF-3M Cooling Stand
|
1 Set
|
Performs secondary constant-temperature cooling and all-round uniform heat dissipation to ensure highly consistent performance and dimensions of the entire bar.
|
|
7
|
Electrical Control Cabinet
|
1 Set
|
Realizes full-line automatic intelligent control, precisely regulates core parameters such as temperature, speed and tension, and ensures excellent process stability.
|
The center height of the production line equipment is controlled at 1100±50mm, which supports the stable production of large-size and large-specification bars. The full automatic closed-loop production greatly reduces manual errors, achieves a higher yield rate, and supports long-term stable mass supply.
IV. Product Specification Parameters
1. Applicable Raw Materials
Adopts high-purity virgin PEEK resin and high-grade POM resin without recycled materials or impurities. The high raw material purity guarantees core properties such as wear resistance, high temperature resistance and corrosion resistance from the source, and avoids cracking, deformation and performance attenuation caused by inferior raw materials.
2. Conventional Size Range
Bar diameter specification: 8mm - 100mm, covering all conventional industrial application sizes. Custom production of special specifications is supported to meet personalized processing needs of customers.
V. Core Excellent Product Performance
1. Extreme High Temperature Resistance
PEEK bar has a glass transition temperature of 143℃ and a melting point of 343℃, with a long-term continuous service temperature of 250-260℃ and an instantaneous peak service temperature of 320℃. It will not soften, deform or suffer sharp strength loss in high-temperature environments. Its thermal deformation stability is far superior to ordinary engineering plastics, making it suitable for long-term use in high-temperature working condition equipment parts.
2. Superior Mechanical Properties
The product balances rigidity and toughness, with excellent tensile resistance, compression resistance and impact resistance. Its fatigue resistance under alternating stress is comparable to alloy materials. It is not easy to wear, break or deform under long-term high-load operation, and features excellent dimensional stability, ideal for processing various precision transmission and load-bearing parts to effectively extend equipment service life.
3. Excellent Self-Lubricating & Wear Resistance
No additional lubricating oil is required. The material features inherent excellent self-lubricating performance with a low friction coefficient and low wear loss. Under high-speed friction and reciprocating motion conditions, its wear capacity is much lower than ordinary plastics such as nylon and POM. It can perfectly replace metal wear parts like copper and iron, reducing equipment operating noise and maintenance costs.
4. Corrosion & Weather Resistance with Stable Performance
It resists corrosion from acid, alkali, salt, organic solvents, oil and water without dissolution, aging or mildew, adapting to harsh working conditions of chemical and fluid equipment. Meanwhile, it has outstanding UV resistance and anti-aging performance, avoiding discoloration and embrittlement after long-term outdoor and static use, with an ultra-long service life.
5. Superior Insulation & Flame Retardancy
It maintains stable dielectric properties under normal and high-temperature conditions with high insulation strength and low leakage loss, serving as a high-quality insulating raw material for high-end electronics, electrical appliances and precision instruments. The product has inherent flame retardancy with a high flame retardant grade, no toxic and harmful substance precipitation, complying with industrial safety and environmental protection standards.
6. Easy Processing & Eco-Friendly
With uniform and dense texture, the bars support precision processing such as turning, milling, drilling and cutting without edge chipping or cracking, ensuring high finished product accuracy. The material is non-toxic, odorless and eco-friendly, applicable for manufacturing compliant parts of medical and food equipment.
VI. Core Product Advantages
1. Independent R&D Technology & Controllable Quality: Relying on self-developed production technology, we optimize the whole process of extrusion, cooling and shaping, solving common industry pain points such as bar eccentricity, large internal stress and uneven performance, achieving higher consistency and stability of finished products.
2. Large Factory Capacity & Stable Supply: With an 80,000-square-meter standardized production base and complete automatic production lines, we possess sufficient daily output and flexible production scheduling capabilities. We can stably meet customers' bulk order demands and urgent order needs, providing reliable and long-term supply guarantee for global partners.
3. Strict Quality Inspection & High Cost Performance: We implement full-process quality monitoring from raw material incoming inspection, production process tracking to finished product delivery inspection. All products reach high industrial standards. On the premise of ensuring top-tier performance and quality, we eliminate intermediate links and offer favorable factory direct sales prices with outstanding cost performance.
4. Customized Service & Wide Applicability: We support customized production of different diameters, lengths and special performance requirements. Our PEEK bars are widely used in aerospace, medical equipment, semiconductor electronics, mechanical automation, chemical engineering, automobile manufacturing and other industries, providing tailored material solutions for various high-end industrial scenarios.
